Classification of Water and Powder Mixing Pump
1、According to structure
Vertical water and powder mixing pump and split water and powder mixing pump. And each type has various models for choose.
2、According to appearance
Sanitary water and powder mixing pump and common water and powder mixing pump .
Usages of Water and Powder Mixing Pump
It is widely used in food industry, medicine industry, chemical industry, daily industry etc such as soy, fruit sauce, peanut sauce, milk sauce, dyestuff, flower powder, etc.
Technical Parameters of Water and Powder Mixing Pump
|
Name |
Model |
Main Technical Parameter | |||
|
Vertical Water and Power Mixing Pump |
THJ-L20 |
Rated flow: |
20000 L/H | ||
|
Max. pressure head: |
3*10 mm | ||||
|
Impeller diameter: |
￠170mm | ||||
|
Liquid-in pipe diameter: |
￠38*1.5mm | ||||
|
Material-in pipe diameter: |
80mm | ||||
|
Liquid –out pipe diameter: |
￠38*1.5mm | ||||
|
Motor |
Power: |
4KW | |||
|
Speed: |
2900r/m | ||||
|
Overall size: |
420*420*1050mm | ||||
|
Weight: |
82KG | ||||
|
Split Water and Power Mixing Pump |
THJ-F20 |
Rated flow: |
20000L/H | ||
|
Max. pressure head: |
3*10 mm | ||||
|
Impeller diameter: |
￠170mm | ||||
|
Liquid-in pipe diameter: |
￠40*1.5mm | ||||
|
Material-in pipe diameter: |
80mm | ||||
|
Liquid –out pipe diameter: |
￠40*1.5mm | ||||
|
Motor |
Power: |
5.5KW |
7.5KW | ||
|
Speed: |
2000-2900r/m | ||||
|
Overall size: |
950*450*1150mm | ||||
|
Weight: |
220KG | ||||
Water and Powder Mixing Pump Finished Picture
